ال automatic round bottle labeling machine is designed for applying labels to round bottles and containers in the food, beverage, pharmaceutical, cosmetic, and daily chemical industries. It supports both full-wrap and partial-wrap labeling, with a capacity of 30–80 bottles per minute and a labeling accuracy of ±1 mm.
The bottle labeler machine handles bottles with diameters of 25–100 mm and heights of 25–230 mm, making it suitable for different bottle labeling requirements. Optional date coding, transparent label detection, and automatic bottle feeding are available to meet specific packaging needs.
Round bottle sticker labeling machine working video
Watch the video below to see how the automatic round bottle labeling machine applies labels to round bottles. The video shows the bottle feeding, label application, and rolling process, helping you understand how the machine works during operation.
Key features of round bottle labeling machine
1. Full-wrap and partial-wrap labeling
The machine can apply labels around the entire circumference of a round bottle or cover only part of the surface. Operators can adjust the labeling position and relevant settings when switching between compatible bottle and label sizes.
2. Automatic bottle separation and label detection
The bottle separation mechanism creates suitable gaps between products, while the photoelectric detection system triggers label dispensing. The machine also supports automatic label correction and label detection functions to help reduce missed labels and unnecessary label waste.
3. Smooth label application
A flexible rolling belt presses and rolls the label onto the bottle surface. This helps reduce wrinkles and uneven application, improving the appearance of the finished package.
4. Adjustable labeling speed
The labeling speed, conveyor speed, and bottle separation speed can be adjusted according to production requirements. The rated labeling speed is 30–80 bottles per minute, depending on bottle dimensions, label size, and operating conditions.
5. Durable construction and centralized control
The round bottle labeling machine uses a stainless steel and aluminum alloy structure. Its control cabinet houses the PLC and electrical components, while the human-machine interface allows operators to adjust operating parameters.
What products can this bottle labeler machine handle?
This round bottle labeling machine is suitable for round bottles and containers with diameters of 25–100 mm and heights of 25–230 mm. The actual compatibility depends on the product’s shape and proportions.
Typical applications include:
- PET and plastic bottles
- Glass bottles
- Food cans and cylindrical containers
- Cosmetic and personal care bottles
- Pharmaceutical and chemical containers
- Bottles used for food, beverages, and daily chemical products
It works with self-adhesive labels, adhesive films, barcodes, and electronic supervision codes. The machine supports full-wrap labeling around the bottle or partial-wrap labeling, depending on the label size and application requirements.
Technical parameters of automatic labeling machines
| حجم الأيقونة | Specification |
|---|---|
| Applicable bottle diameter | 25–100 mm |
| Applicable bottle height | 25–230 mm |
| Label length | 20–285 mm |
| Label width, including backing paper | 15–160 mm |
| Labeling speed | 30–80 bottles/min |
| Labeling accuracy | ±1 mm, excluding bottle and label errors |
| أبعاد الآلة | Approx. 1950 × 1120 × 1340 mm |
| مزود الطاقة | 220 V / 50 Hz |
| وزن الآلة | Approx. 150 kg |
Actual labeling performance depends on the bottle shape, label dimensions, label material, and selected configuration. Before ordering, confirm the bottle dimensions and label specifications to ensure compatibility.
Main structure of automatic round bottle labeler
The automatic round bottle labeling machine consists of seven main components. Each part plays a role in product conveying, label application, position adjustment, or operation control.
| Component | Function |
|---|---|
| 1. Human-machine interface | Allows operators to set and adjust machine parameters through the control interface. |
| 2. Label rolling mechanism | Rolls and presses labels onto the bottle surface to improve adhesion and reduce wrinkles. |
| 3. Conveyor system | Transports bottles to the labeling position and moves labeled products to the collection area. |
| 4. Electrical control cabinet | Houses the PLC and electrical components that coordinate machine operation. |
| 5. Adjustment mechanism | Moves the label head up, down, left, or right to align it with the required labeling position. |
| 6. Label head | Feeds and applies labels to bottles according to the product detection signal. |
| 7. Bottle separation mechanism | Adjusts the spacing between bottles by controlling motor speed, providing sufficient time for labeling. |
Optional functions for different packaging needs
Different products may require additional printing, inspection, or positioning functions. The following options can be selected according to the packaging process.
| ptional configuration | Main function |
|---|---|
| Thermal ribbon coder | Prints production dates, batch numbers, and other information on labels |
| Online inkjet printer | Prints dates, codes, or other information during production |
| Barcode printer | Prints barcodes or other variable information |
| Transparent label sensor | Detects transparent self-adhesive labels |
Round bottle labeling machine price and ROI analysis
Price:
The price of an automatic round bottle labeler machine depends on its configuration. A standard model costs less than a system equipped with an automatic bottle unscrambler, date coder, or additional labeling units.
ROI:
For example, if a business labels 2,000 bottles per week, manual labeling at 8 bottles per minute requires approximately 217 hours per year. At an illustrative machine speed of 40 bottles per minute, the same volume requires about 43 hours of labeling time. At a labor rate of $18 per hour, this represents approximately 173 hours of potential labor capacity released annually, equivalent to about $3,120 in labor time.
FAQ about automatic round bottle labeling machine
Can the machine label both plastic and glass bottles?
Yes. It can handle compatible round plastic and glass bottles, including PET bottles.
Can it apply full-wrap and partial-wrap labels?
Yes. Both labeling types are supported. The setup depends on the bottle diameter, label length, and required labeling position.
Can it work with transparent labels?
Yes, with an optional transparent label sensor. Compatibility should be confirmed based on the specific label material and sensor requirements.
Can it connect to an existing packaging line?
Yes. The round bottle labeling machine can be integrated with machines such as a filling machine and a capping machine to form a filling line.
What information is needed for a quotation?
Provide the bottle diameter and height, label dimensions, labeling coverage, required output, power supply requirements, and any printing or automation needs. Photos or samples of the bottle and label can help confirm the configuration.
اتصل بنا على الفور!
Whether you need to label PET bottles, glass bottles, food containers, or cosmetic packaging, the right configuration depends on your bottle dimensions, label requirements, and target output.
Contact us with your product details and packaging requirements. We can help assess machine compatibility, recommend suitable optional functions, and provide a quotation based on your actual production needs.
